Volkswagen Passat (North America) II (2019-2022) left coupling point in engine/ motor compt Wiring diagram
This page shows the only wiring diagram for the component.left coupling point in engine/ motor compt, which is found in the car Volkswagen Passat (North America) II (2019-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left coupling point in engine/ motor compt (1 of 1)
A/C CLUTCH RELAY
A/C COMPRESSOR REGULATOR VALVE
ADAPTIVE CRUISE CONTROL MODULE
AMPLIFIER
BLK WIRE
BOTTOM LEFT COUPLING POINT ON ENGINE
BRAKE FLUID LEVEL WARNING SWITCH
BRN WIRE
EMERGENCY CALL BUTTON
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
ENGINE HOOD CONTACT SWITCH
ENGINE/MOTOR CONTROL MODULE
FUSE PANEL B
HEATER SUPPORT PUMP
IGNITION COIL 1 W/ POWER OUTPUT STAGE
IGNITION COIL 2 W/ POWER OUTPUT STAGE
IGNITION COIL 3 W/ POWER OUTPUT STAGE
IGNITION COIL 4 W/ POWER OUTPUT STAGE
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT COUPLING POINT IN ENGINE/ MOTOR COMPT
LEFT COUPLING POINT IN ENGINE/MOTOR COMPT
LEFT FRONT HEADLAMP
LEFT HORN
MULTI-FUNCTION TRANSMISSION RANGE SWITCH
OIL LEVEL THERMAL SENSOR
RADIATOR FAN
REAR LID CAMERA
SECONDARY AIR INJECTION PUMP MOTOR
TRANSMISSION CONTROL MODULE
W/ ADAPTIVE CRUISE CONTROL W/O ADAPTIVE CRUISE CONTROL
W/O ADAPTIVE CRUISE CONTROL W/ ADAPTIVE CRUISE CONTROL
WHT WIRE
WIPER MOTOR CONTROL MODULE
WIPER MOTOR RELAY 2
Go to component -> Ground distribution circuit (1 of 4) -> LEFT COUPLING POINT IN ENGINE/ MOTOR COMPT
