Headlights circuit for Volkswagen Passat (North America) I facelift (2015-2019)

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM FRONT FOG LAMP SWITCH FUSE 15 FUSE 23 FUSE PANEL C GRY WIRE GRY/WHT WIRE GRY/YEL WIRE HEADLAMP SWITCH ILLUMINATION BULB HIGH BEAM IND LAMP HOT AT ALL TIMES HOT W/ TERMINAL 15 RELAY ENERGIZED INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE LEFT FOG LAMP LEFT FRONT HEADLAMP LEFT HIGH BEAM HEADLAMP BULB LEFT LOW BEAM HEADLAMP BULB LIGHT SWITCH ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE PARKING BRAKE INDICATOR LAMP SWITCH REAR FOG LAMP SWITCH RED/WHT WIRE RED/YEL WIRE RIGHT FOG LAMP ROTARY LIGHT SWITCH VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE W/ LED HEADLAMPS W/O LED HEADLAMPS WHT WIRE WHT/BLK WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE

AIR CONDITIONING SYSTEM BLK/GRN WIRE BLU WIRE BRN WIRE CLIMATRONIC CONTROL MODULE COMPUTER COMPUTER DATA LINES SYSTEM DATA LINES GRN/BLU WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE HEADLAMP DIMMER/ FLASHER SWITCH NCA WIRE ORG/BRN WIRE ORG/GRN WIRE RIGHT FRONT HEADLAMP RIGHT HIGH BEAM HEADLAMP BULB RIGHT LOW BEAM HEADLAMP BULB STEERING COLUMN ELECTRONICS CONTROL MODULE SUNLIGHT PHOTO SENSOR SUNLIGHT PHOTO SENSOR 2 SYSTEM TURN SIGNAL SWITCH W/ LED HEADLAMPS W/O LED HEADLAMPS WHT/BLU WIRE WHT/VIO WIRE YEL/BLU WIRE
