Volkswagen Passat (North America) I facelift (2015-2019) daytime running lamp indicator Wiring diagram
This page shows the only wiring diagram for the component.daytime running lamp indicator, which is found in the car Volkswagen Passat (North America) I facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram daytime running lamp indicator (1 of 1)
BACKUP LAMPS CIRCUIT
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DAYTIME RUNNING LAMP INDICATOR
FUSE
FUSE PANEL C
GRN/RED WIRE
GRY/BLK WIRE
GRY/RED WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
LEFT BACKUP LAMP
LEFT BRAKE/ TAIL LAMP
LEFT BRAKE/ TURN SIGNAL LAMP
LEFT LICENSE PLATE
LEFT TAIL LAMP
LEFT TAIL LAMP 2
LEFT TURN SIGNAL INDICATOR LAMP
LIGHT SWITCH
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
PARKING BRAKE INDICATOR LAMP SWITCH
REAR FOG LAMP
REAR FOG LAMP SWITCH
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT LICENSE PLATE
RIGHT TURN SIGNAL INDICATOR LAMP
ROTARY LIGHT SWITCH
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Exterior lamps circuit, w/ led headlamps (1 of 3) -> DAYTIME RUNNING LAMP INDICATOR
