Front heated seats circuit for Volkswagen Jetta VII facelift (2021-2024)
Front heated seats circuit
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER SIDE HEATED SEAT
FUSE 26
FUSE PANEL C
GRN WIRE
GRY WIRE
HEATED DRIVER SEAT INDICATOR LAMP
HEATED FRONT PASSENGER SEAT INDICATOR LAMP
HEATER, A/C CONTROLS
HOT AT ALL TIMES
LEFT FRONT SEAT COUPLING STATION
LEFT FRONT SEAT HEATED BACKREST
LEFT FRONT SEAT HEATING ELEMENT
LEFT FRONT SEAT TEMPERATURE SENSOR
LEFT SEAT HEATING BUTTON
NCA WIRE
ORG/BRN WIRE
PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT SEAT COUPLING STATION
RIGHT FRONT SEAT HEATED BACKREST
RIGHT FRONT SEAT HEATING ELEMENT
RIGHT FRONT SEAT TEMPERATURE SENSOR
RIGHT SEAT HEATING BUTTON
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
