Parking assistant circuit for Volkswagen Jetta VII facelift (2021-2024)

BLK/GRN WIRE BLK/YEL WIRE BLU WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/RED WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM FRONT PARKING AID WARNING BUZZER FUSE 32 FUSE 34 FUSE PANEL C GRY WIRE HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT LEFT FRONT CENTER PARKING AID SENSOR LEFT FRONT PARKING AID SENSOR ORG/BRN WIRE PARKING AID CONTROL MODULE RED/GRN WIRE RED/YEL WIRE RIGHT FRONT CENTER PARKING AID SENSOR RIGHT FRONT PARKING AID SENSOR VIO WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/RED WIRE WHT WIRE YEL WIRE

ABS CONTROL MODULE BLK/YEL WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BOTTOM LEFT COUPLING POINT IN INTERIOR BRN WIRE BRN/RED WIRE BRN/YEL WIRE CENTER CONSOLE SWITCH MODULE 2 COMPUTER DATA LINES SYSTEM GRY WIRE LEFT REAR CENTER PARKING AID SENSOR LEFT REAR PARKING AID SENSOR ORG/BRN WIRE PARALLEL PARKING ASSISTANCE BUTTON PARALLEL PARKING ASSISTANCE INDICATOR LAMP PARKING AID BUTTON PARKING AID INDICATOR LAMP PUSH BUTTON ILLUMINATION BULB RED/YEL WIRE RIGHT COUPLING POINT IN LUGGAGE COMPARTMENT RIGHT REAR CENTER PARKING AID SENSOR RIGHT REAR PARKING AID SENSOR VIO/GRN WIRE VIO/GRY WIRE VIO/RED WIRE WHT WIRE
