Volkswagen Jetta VII (2018-2021) Parking assistant circuit

BLK/GRN WIRE BLK/YEL WIRE BLU WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/RED WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM FRONT PARKING AID WARNING BUZZER FUSE 32 FUSE 34 FUSE PANEL C GRY WIRE HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT LEFT FRONT CENTER PARKING AID SENSOR LEFT FRONT PARKING AID SENSOR ORG/BRN WIRE PARALLEL PARKING ASSISTANCE CONTROL MODULE PARKING AID CONTROL MODULE REAR PARKING AID WARNING BUZZER RED/GRN WIRE RED/YEL WIRE RIGHT FRONT CENTER PARKING AID SENSOR RIGHT FRONT PARKING AID SENSOR VIO WIRE VIO/BLU WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE YEL WIRE

ABS CONTROL MODULE AID BUTTON ASSISTANCE) BLK/YEL WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BOTTOM RIGHT COUPLING POINT IN INTERIOR BRN WIRE BRN/RED WIRE BRN/YEL WIRE BULB BUTTON CENTER CONSOLE SWITCH MODULE 2 COMPUTER DATA LINES SYSTEM GRY WIRE ILLUMINATION INDICATOR LAMP LEFT REAR CENTER PARKING AID SENSOR LEFT REAR PARKING AID SENSOR ORG/BRN WIRE PARALLEL PARKING PARKING AID PUSH BUTTON RED/YEL WIRE RIGHT COUPLING POINT IN LUGGAGE COMPARTMENT RIGHT REAR CENTER PARKING AID SENSOR RIGHT REAR PARKING AID SENSOR VIO/GRN WIRE VIO/GRY WIRE VIO/RED WIRE WHT WIRE
