Volkswagen Jetta VII (2018-2021) Manual a/c circuit

A/C CLUTCH RELAY A/C CONTROL MODULE AIR DISTRIBUTION DOOR AIR DISTRIBUTION DOOR MOTOR AIR DISTRIBUTION DOOR MOTOR, POSITION SENSOR BLK/BLU WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/YEL WIRE BOTTOM LEFT COUPLING POINT IN INTERIOR BRN WIRE COMPRESSOR MAGNETIC CLUTCH COMPUTER DATA LINES SYSTEM EVAPORATOR TEMPERATURE SENSOR FRESH AIR BLOWER FRESH AIR BLOWER CONTROL MODULE FUSE 14 FUSE 29 FUSE 34 FUSE 42 FUSE 7 FUSE PANEL C GRN WIRE GRN/BLK WIRE GRY WIRE GRY/RED WIRE HEATER, A/C CONTROLS HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED INSTRUMENT CLUSTER CONTROL MODULE INSTRUMENT CLUSTER LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT N/A ORG/BRN WIRE RECIRCULATION DOOR MOTOR RED WIRE RED/BLK WIRE RED/BLU WIRE RED/YEL WIRE REFRIGERANT CIRCUIT PRESSURE SENSOR TEMPERATURE CONTROL DOOR TEMPERATURE CONTROL DOOR MOTOR TEMPERATURE CONTROL DOOR MOTOR, POSITION SENSOR VIO WIRE VIO/RED WIRE VIO/YEL WIRE YEL WIRE YEL/BLK WIRE

A/C COMPRESSOR REGULATOR VALVE BLK WIRE BLK/RED WIRE BLU WIRE BLU/BRN WIRE BLU/YEL WIRE BOTTOM LEFT COUPLING POINT IN INTERIOR BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/VIO WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM ENGINE CONTROLS SYSTEM ENGINE COOLANT LEVEL SENSOR ENGINE COOLANT TEMPERATURE SENSOR ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET ENGINE/MOTOR CONTROL MODULE FUSE 17 FUSE 4 FUSE 5 FUSE 7 FUSE PANEL A FUSE PANEL B GRN WIRE GRN/BLK WIRE HOT AT ALL TIMES HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT LOW TEMPERATURE CIRCUIT COOLANT PUMP NCA WIRE ORG/BRN WIRE OUTSIDE AIR TEMPERATURE SENSOR RADIATOR FAN RADIATOR FAN 2 RADIATOR FAN CONTROL MODULE (RADIATOR FAN ASSEMBLY) RADIATOR SHUTTER MOTOR RED/BLK WIRE RED/BLU WIRE RED/YEL WIRE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/RED WIRE VIO/WHT WIRE VIO/YEL WIRE WHT/YEL WIRE WINDSHIELD WASHER FLUID LEVEL SENSOR
