Volkswagen Jetta V (2005-2011) door locks system computer data lines system wiring diagram
This page shows the only wiring diagram for the component.door locks system computer data lines system, which is found in the car Volkswagen Jetta V (2005-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
door locks system computer data lines system wiring diagram (1 of 1)
ANTI-THEFT SYSTEM
BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRY WIRE
BRN/YEL WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
DOOR LOCKS SYSTEM COMPUTER DATA LINES SYSTEM
FUSE 24
FUSE PANEL
HOT AT ALL TIMES
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
POWER TOPS SYSTEM
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/VIO WIRE
SEDAN
SEDAN WAGON
TRUNK, TAILGATE, FUEL DOORS SYSTEM
TRUNK, TAILGATE, FUEL DOORS SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS
VIO/GRN WIRE
VIO/GRY WIRE
WAGON
YEL WIRE
Go to component -> Comfort system central control module circuit -> DOOR LOCKS SYSTEM COMPUTER DATA LINES SYSTEM
