Volkswagen Jetta IV (1998-2005) Power door locks circuit, sedan

ALARM SYSTEM ANTI- THEFT FUSE ANTI-THEFT SYSTEM BLK WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/GRY WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CENTRAL LOCKING WARNING LIGHT (SAFE) CENTRAL LOCKING, ANTI-THEFT WARNING SYSTEM ANTENNA CENTRAL LOCKING/ ANTI- THEFT FUSE CIRCUIT BREAKER COMFORT SYSTEM CENTRAL CONTROL MODULE (BEHIND LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM DEFOGGER OR MIRRORS SYSTEM DEFOGGERS SYSTEM DOOR AJAR INDICATOR DRIVER'S SIDE CENTRAL LOCKING LOCK UNIT DRIVER'S SIDE DOOR CONTROL MODULE (IN DRIVER'S DOOR, INTEGRAL WITH WINDOW MOTOR) DRIVER'S SIDE INTERIOR LOCK SWITCH EXTERIOR LIGHTS SYSTEM INSTRUMENT CLUSTER SYSTEM FUSE GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE PANEL (BEHIND LEFT SIDE OF DASH) FUSE INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM NCA WIRE ORG/ WIRE ORG/BRN WIRE ORG/GRN WIRE POWER TOPS SYSTEM POWER WINDOW CIRCUIT BREAKER (UNDER LEFT SIDE OF DASH) REAR LID AJAR INDICATOR RED WIRE RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE RED/WHT WIRE RED/YEL WIRE TRUNK LOCK ALARM/ CENTRAL LOCKING SWITCH TRUNK, TAILGATE, FUEL DOORS SYSTEM VIO WIRE VIO/YEL WIRE WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE

BLU WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE BRN/YEL WIRE DECKLID CENTRAL LOCKING SYSTEM MOTOR DEFOGGER SYSTEM GOLF, GTI GRN WIRE GRN/VIO WIRE GRY WIRE GRY/VIO WIRE LEFT REAR CENTRAL LOCKING LOCK UNIT LEFT REAR DOOR CONTROL MODULE (IN LEFT REAR DOOR, INTEGRAL WITH WINDOW MOTOR) NOT USED ORG/BRN WIRE ORG/GRN WIRE PASSENGER'S SIDE CENTRAL LOCKING LOCK UNIT PASSENGER'S SIDE INTERIOR LOCK SWITCH REAR LID UNLOCK MOTOR RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT REAR CENTRAL LOCKING LOCK UNIT RIGHT REAR DOOR CONTROL MODULE (IN RIGHT REAR DOOR, INTEGRAL WITH WINDOW MOTOR) VIO WIRE VIO/BLU WIRE VIO/GRN WIRE VIO/YEL WIRE WHT WIRE YEL WIRE
