Wiring diagram engine performance 2.0l, engine code bbw for Volkswagen Jetta IV (1998-2005)

A/C SYSTEM BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/GRN WIRE BLU/RED WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM FUEL PUMP RELAY FUSE 163 FUSE 29 FUSE 37 FUSE PANEL FUSE/ BRACKET BATTERY GRN WIRE GRN/BRN WIRE GRN/GRY (OR GRN) WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/RED WIRE GRY/WHT WIRE HEATED OXYGEN HOT AT ALL TIMES HOT IN RUN OR START IGNITION SWITCH LEAK DETECTION PUMP (IN RIGHT REAR WHEELHOUSE) LOCK MOTRONIC ENGINE CONTROL MODULE (AT BASE OF WINDSHIELD IN CENTER OF PLENUM) NCA WIRE ORG/BLK WIRE ORG/BRN WIRE OXYGEN POWER SUPPLY RELAY RED WIRE RED/BLK WIRE RED/BRN WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RELAY PANEL RUN WIRE STARTING/ CHARGING SYSTEM THROTTLE POSITION SENSOR/ ACCEL PEDAL POSITION SENSOR VIO WIRE VIO/GRN WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/RED WIRE WHT/YEL WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/RED WIRE

A/T BLK WIRE BLK/VIO WIRE BLU WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRAKE SYSTEM VACUUM PUMP BRAKE VACUUM PUMP FUSE BRN WIRE BRN/RED WIRE BRN/YEL WIRE ENGINE SPEED (RPM) SENSOR (ON LEFT SIDE OF ENGINE BLOCK) FUEL PUMP (IN FUEL TANK) FUSE 1 FUSE 28 FUSE 32 FUSE 34 FUSE 43 FUSE PANEL FUSE/ BRACKET BATTERY GRN WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE GRY/BRN WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES INSTUMENT CLUSTER KNOCK SENSOR 1 (ON LEFT FRONT SIDE OF ENGINE BLOCK) KNOCK SENSOR 2 (BEHIND IGNITION COIL) MALFUNCTION INDICATOR LAMP NCA WIRE RED WIRE RED/BLK WIRE RED/VIO WIRE RELAY PANEL SECONDARY AIR INJECTION PUMP MOTOR (ON LEFT REAR SIDE OF ENGINE) SECONDARY AIR INJECTION PUMP RELAY (IN LEFT SIDE OF ENGINE COMPT) WHT WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE

BLK WIRE BLK/VIO WIRE BLU WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/YEL WIRE BRAKE LIGHT SWITCH (ABOVE BRAKE PEDAL) BRN WIRE BRN/BLU WIRE CAMSHAFT POSITION SENSOR (BEHIND CAMSHAFT SPROCKET) CLUTCH VACUUM VENT VALVE SWITCH (ABOVE CLUTCH PEDAL) CRUISE CONTROL SYSTEM FUEL INJECTORS FUSE 13 FUSE 5 FUSE FOR VALVE CAMSHAFT ADJUSTMENT FUSE PANEL (BEHIND LEFT SIDE OF DASH) GRN WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES MOTRONIC ENGINE CONTROL MODULE (AT BASE OF WINDSHIELD IN CENTER OF PLENUM) NCA WIRE RED WIRE RED/BLK WIRE RED/VIO WIRE TEMPERATURE SENSOR 1 FOR CATALYST THROTTLE VALVE CONTROL MODULE (ON THROTTLE BODY) TO SPARK PLUG VALVE 1 FOR CAMSHAFT ADJUSTMENT VIO WIRE VIO/BLU WIRE VIO/GRN WIRE VIO/RED WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE
