Volkswagen Jetta III (1992-1998) trunk lid alarm switch rear window wiper motor Wiring diagram
This page shows the only wiring diagram for the component.trunk lid alarm switch rear window wiper motor, which is found in the car Volkswagen Jetta III (1992-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trunk lid alarm switch rear window wiper motor (1 of 1)
1995 ONLY
2/31
BRN WIRE
CENTRAL LOCKING SYSTEM PUMP, CONTROL MODULE
DRIVER'S POWER WINDOW SWITCH ASSEMBLY
HIGH MOUNT BRAKE LIGHT
LEFT BACK-UP/ BRAKE LIGHT BULB HOLDER
LEFT FOG LIGHT
LEFT FRONT PARK/TURN SIGNAL LIGHT
LEFT FRONT POWER WINDOW CONTROL MODULE
LEFT FRONT SIDE MARKER LIGHT
LEFT HEADLIGHT
LEFT HEATED MIRROR
LEFT LICENSE PLATE LIGHT
LEFT REAR POWER WINDOW CONTROL MODULE
LEFT REAR POWER WINDOW SWITCH
LEFT TAILLIGHT BULB HOLDER
NCA WIRE
POWER MIRROR SWITCH
POWER WINDOW CONTROL MODULE
REAR WINDOW DEFOGGER
RIGHT BACK-UP/ BRAKE LIGHT BULB HOLDER
RIGHT FOG LIGHT
RIGHT FRONT PARK/TURN SIGNAL LIGHT
RIGHT FRONT POWER WINDOW SWITCH
RIGHT FRONT SIDE MARKER LIGHT
RIGHT HEADLIGHT
RIGHT HEATED MIRROR
RIGHT LICENSE PLATE LIGHT
RIGHT REAR POWER WINDOW SWITCH
RIGHT TAILLIGHT BULB HOLDER
TG/2 TH/2
TJ/2
TO BATTERY (DIAGRAM (1 OF 6)
TRUNK LID ALARM SWITCH REAR WINDOW WIPER MOTOR
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (3 of 6) -> TRUNK LID ALARM SWITCH REAR WINDOW WIPER MOTOR
