Volkswagen Jetta III (1992-1998) seat belt warning system relay Wiring diagrams
This page contains all the electrical diagrams for the component. seat belt warning system relay, in which he is found in the car Volkswagen Jetta III (1992-1998). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
seat belt warning system relay wiring diagram (1 of 2)
A/T
AIRBAG MULTI- FUNCTION INDICATOR LAMP
ALARM SYSTEM CONTROL AIRBAG CONTROL MODULE
BACK-UP LIGHT SWITCH
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
CASSETTE STORAGE LIGHT
CRUISE CONTROL SWITCH POWER MIRROR SWITCH
D/11
D/9
DRIVER'S SEAT HEATER CONTROL MODULE
DRIVER'S SEAT HEATER SWITCH
DUAL HORN RELAY
DUAL HORNS
E/2 D/8
ENGINE CONTROL MODULE
EX 1995 2.8L
F/6 X/4
FROM FUSE/ RELAY PANEL
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 17
FUSE 51
GRN WIRE
IGNITION SWITCH
INSTRUMENT CLUSTER
J/C TV 5 (BEHIND FUSE/ RELAY PANEL)
LEFT REAR POWER WINDOW CONTROL MODULE
LEFT REAR POWER WINDOW SWITCH (EX CABRIO)
LOCK
M/5
M/T
MODULE
MULTI- FUNCTION TRANSMISSION RANGE SWITCH TRANSMISSION CONTROL MODULE
PARK/ NEUTRAL POSITION RELAY
RED WIRE
RED/BLK WIRE
RIGHT FRONT MAP/ READING LIGHT
RIGHT REAR POWER WINDOW SWITCH (EX CABRIO)
SEAT BELT WARNING SYSTEM RELAY
SHIFT LOCK SOLENOID PASSENGER'S SEAT HEATER CONTROL MODULE
SUNROOF SWITCH LIGHT MOTRONIC ENGINE CONTROL MODULE (1996 ONLY)
TO FUSE/ RELAY PANEL (15) (DIAGRAM 3 OF 3)
TO FUSE/ RELAY PANEL (POWER SUPPLY RELAY) (DIAGRAM 1 OF 3)
TO FUSE/RELAY PANEL
TO FUSE/RELAY PANEL (LOAD REDUCTION RELAY) (DIAGRAM 1 OF 3)
TRANSMISSION CONTROL MODULE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 3) -> SEAT BELT WARNING SYSTEM RELAY
seat belt warning system relay wiring diagram (2 of 2)
BLK WIRE
BLK/YEL WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
FUSE/ RELAY PANEL (UNDER LEFT SIDE OF DASH)
GRY WIRE
HOT AT ALL TIMES
IGNITION/ STARTER SWITCH
INSTRU- MENT CLUSTER SEAT BELT WARNING LIGHT
K/11
KEY-IN IGN
L/2
L/4
LEFT FRONT DOOR CONTACT SWITCH
LEFT SEAT BELT SWITCH
LOCK
RADIO
RED WIRE
SEAT BELT WARNING SYSTEM RELAY
YEL (OR WHT) WIRE
Go to component -> Warning system circuits -> SEAT BELT WARNING SYSTEM RELAY
