Volkswagen Jetta III (1992-1998) right rear power window control module Wiring diagram
This page shows the only wiring diagram for the component.right rear power window control module, which is found in the car Volkswagen Jetta III (1992-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear power window control module (1 of 1)
* - INFORMATION NOT AVAILABLE
BLK WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRY WIRE
BRN/WHT WIRE
BRN/YEL (OR BRN/WHT) WIRE
BRN/YEL WIRE
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
ILLUMINATION
ILLUMINATION (3)
LEFT FRONT WINDOW SWITCH
LEFT REAR POWER WINDOW CONTROL MODULE
LEFT REAR WINDOW SWITCH
NCA WIRE
POWER WINDOW CONSOLE SWITCH ASSEMBLY
RED/YEL WIRE
RIGHT REAR POWER WINDOW CONTROL MODULE
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR WINDOW SWITCH
WINDOW LOCKOUT SWITCH
WINDOW MOTOR
Go to component -> Power window circuit (2 of 2) -> RIGHT REAR POWER WINDOW CONTROL MODULE
