Volkswagen Jetta III (1992-1998) right make-up mirror light Wiring diagram
This page shows the only wiring diagram for the component.right make-up mirror light, which is found in the car Volkswagen Jetta III (1992-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right make-up mirror light (1 of 1)
1995 ONLY
1995 W/ A/T ONLY
73/1
ALARM SYSTEM CONTROL MODULE
AUTOMATIC TRANSMISSION CONSOLE LIGHT
BLU WIRE
BRN WIRE
CASSETTE STORAGE LIGHT
CENTER REAR ASHTRAY LIGHT
CRUISE CONTROL MODULE
DRIVER'S BACKREST HEAT ELEMENT
DRIVER'S SEAT HEATER CONTROL MODULE
DRIVER'S SEAT HEATER TEMPERATURE SENSOR
FROM BATTERY (DIAGRAM 1 OF 6)
FRONT INTERIOR LIGHT
KICK DOWN SWITCH
LEFT MAKE-UP MIRROR LIGHT
LEFT REAR READING LIGHT
MULTI-FUNCTION TRANSMISSION RANGE SWITCH
PARK/ NEUTRAL POSITION RELAY
PASSENGER'S BACKREST HEAT ELEMENT
POWER SUNROOF CONTROL MODULE
RADIO
RIGHT FRONT MAP/ READING LIGHT
RIGHT MAKE-UP MIRROR LIGHT
RIGHT REAR READING LIGHT
SEAT HEATER SWITCH
TO FUSE/RELAY PANEL (DIAGRAM 1 OF 6)
TRANS- MISSION CONTROL MODULE
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (2 of 6) -> RIGHT MAKE-UP MIRROR LIGHT
