Volkswagen Jetta III (1992-1998) right front power window control module Wiring diagram
This page shows the only wiring diagram for the component.right front power window control module, which is found in the car Volkswagen Jetta III (1992-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front power window control module (1 of 1)
ANTI-THEFT SYSTEM
BLK WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL (OR BRN/WHT) WIRE
BRN/YEL WIRE
D/9
DRIVER'S POWER WINDOW SWITCH ASSEMBLY
FUSE 14
FUSE 43
FUSE/ RELAY PANEL
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
ILLUMINATION
ILLUMINATION (2)
INTERIOR LIGHTS SYSTEM (HEADLIGHT SWITCH)
JUNCTION CONNECTOR (BEHIND FUSE/RELAY PANEL)
LEFT FRONT DOOR CONTACT SWITCH
LEFT FRONT POWER WINDOW CONTROL MODULE
LEFT FRONT WINDOW SWITCH
NCA WIRE
POWER WINDOW INLINE FUSE
RED WIRE
RED/YEL WIRE
RIGHT FRONT POWER WINDOW CONTROL MODULE
RIGHT FRONT POWER WINDOW SWITCH
RIGHT FRONT WINDOW SWITCH
WHT WIRE
WHT/RED WIRE
WINDOW MOTOR
Y/2
YEL WIRE
Go to component -> Power window circuit (1 of 2) -> RIGHT FRONT POWER WINDOW CONTROL MODULE
