Volkswagen Jetta III (1992-1998) left rear woofer left rear tweeter Wiring diagram
This page shows the only wiring diagram for the component.left rear woofer left rear tweeter, which is found in the car Volkswagen Jetta III (1992-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear woofer left rear tweeter (1 of 1)
ANTENNA
ANTI-THEFT SYSTEM
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
GRY/BLU WIRE
HOT AT ALL TIMES FUSE/ RELAY PANEL FUSE 22
HOT AT ALL TIMES IGNITION/
LEFT FRONT TWEETER
LEFT FRONT WOOFER
LEFT REAR WOOFER LEFT REAR TWEETER
LOCK
NCA WIRE
RADIO
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT TWEETER
RIGHT FRONT WOOFER
RIGHT REAR TWEETER
RIGHT REAR WOOFER
SWITCH
TGA
WHT WIRE
Go to component -> Radio circuits -> LEFT REAR WOOFER LEFT REAR TWEETER
