Volkswagen Jetta III (1992-1998) intake air temperature sensor/fuel injector Wiring diagram

BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BRN/BLK WIRE BRN/RED (OR BRN/BLU) WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL (OR BRN/WHT) WIRE BRN/YEL WIRE CAMSHAFT POSITION SENSOR CLOSED THROTTLE POSITION SWITCH CONTROL MODULE EARLY FUEL EVAPORATION HEATING ELEMENT EARLY FUEL EVAPORATION RELAY ENGINE COOLANT TEMPERATURE SENSOR EVAPORATIVE EMISSION CANISTER PURGE REGULATOR VALVE GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/GRN WIRE IGNITION COIL IGNITION COIL POWER OUTPUT STAGE IGNITION DISTRIBUTOR INJECTOR INSTRUMENT CLUSTER INTAKE AIR TEMPERATURE SENSOR/FUEL INJECTOR NCA WIRE RED WIRE RED/BLK WIRE SENSOR VIO WIRE VIO/BLK WIRE VIO/WHT WIRE WHT WIRE
