Volkswagen Jetta III (1992-1998) hot in run or start Wiring diagrams
This page contains all the electrical diagrams for the component. hot in run or start, in which he is found in the car Volkswagen Jetta III (1992-1998). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram hot in run or start (1 of 6)
ABS CONTROL MODULE W/ EDL (LEFT SIDE OF ENG COMPT)
ABS FUSE HOLDER (LEFT SIDE OF ENGINE COMPARTMENT)
ABS HYDRAULIC PUMP
ABS WARNING LIGHT
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BRAKE FLUID LEVEL SWITCH
BRN WIRE
BRN/WHT WIRE
DATA LINK CONNECTOR (ABOVE FUSE/ RELAY PANEL)
DIFFERENTIAL LOCK VALVE 1
DIFFERENTIAL LOCK VALVE 2
FUSE 1
FUSE 2
FUSE 20
FUSE 4
FUSE/ RELAY BOX
FUSE/ RELAY BOX FUSE 16
GRY WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
HOT W/ UNLOADER RELAY ENERGIZED
LEFT FRONT ABS INLET VALVE
LEFT FRONT ABS OUTLET VALVE
LEFT FRONT ABS WHEEL SPEED SENSOR
LEFT REAR ABS INLET VALVE
LEFT REAR ABS OUTLET VALVE
LEFT REAR ABS WHEEL SPEED SENSOR
NCA WIRE
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RIGHT FRONT ABS INLET VALVE
RIGHT FRONT ABS OUTLET VALVE
RIGHT FRONT ABS WHEEL SPEED SENSOR
RIGHT REAR ABS INLET VALVE
RIGHT REAR ABS OUTLET VALVE
RIGHT REAR ABS WHEEL SPEED SENSOR
STOP LIGHT SWITCH
WHT WIRE
YEL/RED WIRE
Go to component -> Anti-lock brake circuits -> HOT IN RUN OR START
Wiring diagram hot in run or start (2 of 6)
A/T
A/T M/T
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BRAKE LIGHT SWITCH (ON BRAKE PEDAL BRACKET)
BRN WIRE
BRN/RED WIRE
CRUISE CONTROL BRAKE PEDAL POSITION SWITCH
CRUISE CONTROL CLUTCH PEDAL POSITION SWITCH
CRUISE CONTROL FUSE FUSE 51
CRUISE CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
CRUISE CONTROL SWITCH
D/11
E/3 E/4
EXCEPT 1998 (BESIDE FUSE/ RELAY PANEL)
FUSE 14
FUSE 20
FUSE/ RELAY PANEL (UNDER LEFT SIDE OF DASH)
FUSE/RELAY PANEL (UNDER LEFT SIDE OF DASH)
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
INSTRUMENT CLUSTER
M/T
RED WIRE
RED/YEL WIRE
TRANSMISSION CONTROL MODULE (TCM) (BELOW LEFT REAR SEAT)
TRANSMISSIONS SYSTEM (TRANSMISSION CONTROL MODULE (TCM))
VIO WIRE
W/1
W/4
YEL WIRE
Go to component -> Cruise control circuit -> HOT IN RUN OR START
Wiring diagram hot in run or start (3 of 6)
Go to component -> Heated windshield washer circuit -> HOT IN RUN OR START
Wiring diagram hot in run or start (4 of 6)
ANTI-THEFT SYSTEM
BLK WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL (OR BRN/WHT) WIRE
BRN/YEL WIRE
D/9
DRIVER'S POWER WINDOW SWITCH ASSEMBLY
FUSE 14
FUSE 43
FUSE/ RELAY PANEL
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
ILLUMINATION
ILLUMINATION (2)
INTERIOR LIGHTS SYSTEM (HEADLIGHT SWITCH)
JUNCTION CONNECTOR (BEHIND FUSE/RELAY PANEL)
LEFT FRONT DOOR CONTACT SWITCH
LEFT FRONT POWER WINDOW CONTROL MODULE
LEFT FRONT WINDOW SWITCH
NCA WIRE
POWER WINDOW INLINE FUSE
RED WIRE
RED/YEL WIRE
RIGHT FRONT POWER WINDOW CONTROL MODULE
RIGHT FRONT POWER WINDOW SWITCH
RIGHT FRONT WINDOW SWITCH
WHT WIRE
WHT/RED WIRE
WINDOW MOTOR
Y/2
YEL WIRE
Go to component -> Power window circuit (1 of 2) -> HOT IN RUN OR START
Wiring diagram hot in run or start (5 of 6)
AIRBAG CONTROL MODULE
AIRBAG MALFUNCTION INDICATOR LAMP
AIRBAG SPIRAL SPRING
BLK WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
DATA LINK CONNECTOR (BEHIND FUSE/RELAY PANEL)
DRIVER'S SIDE AIRBAG IGNITER
FUSE 16
FUSE/ RELAY PANEL (BEHIND LEFT SIDE OF DASH)
GRY WIRE
GRY/WHT WIRE
HOT IN RUN OR START
JUNCTION BOX FOR ON BOARD DIAGNOSTICS (ABOVE FUSE/RELAY BOX)
NCA WIRE
PASSENGER'S SIDE AIRBAG IGNITER
Q/1 D/8
TERMINAL WIRE CONNECTOR
WHT WIRE
X/4 X/2
YEL WIRE
Go to component -> Supplemental restraint circuit, early production -> HOT IN RUN OR START
Wiring diagram hot in run or start (6 of 6)
AIRBAG CONTROL MODULE
AIRBAG MALFUNCTION INDICATOR LAMP
AIRBAG SPIRAL SPRING
BLK WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLK/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
D/8
DATA LINK CONNECTOR (BEHIND FUSE/RELAY PANEL)
DRIVER'S SIDE AIRBAG IGNITER
FUSE/ RELAY PANEL (BEHIND LEFT SIDE OF DASH)
GRN/WHT WIRE
GRY WIRE
GRY/WHT WIRE
HOT IN RUN OR START
JUNCTION BOX FOR ON BOARD DIAGNOSTICS (ABOVE FUSE/RELAY BOX)
NCA WIRE
RED/WHT WIRE
TERMINAL WIRE CONNECTOR
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraint circuit, late production -> HOT IN RUN OR START
