Volkswagen Jetta III (1992-1998) egr part throttle switch engine coolant temperature sensor Wiring diagram
This page shows the only wiring diagram for the component.egr part throttle switch engine coolant temperature sensor, which is found in the car Volkswagen Jetta III (1992-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram egr part throttle switch engine coolant temperature sensor (1 of 1)
1995-96
A/C SYSTEM
AUTOMATIC GLOW TIME CONTROL MODULE
BATTERY
BLK (OR BLK/YEL) WIRE
BLK WIRE
BLK/BLU WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
D/11
EGR PART THROTTLE SWITCH ENGINE COOLANT TEMPERATURE SENSOR
ENGINE GLOW PLUGS
F/5
FUEL CUT- OFF VALVE (1994)
FUEL CUT- OFF VALVE (1995-96)
FUSE 14
FUSE 15
FUSE 39
FUSE/ RELAY PANEL
FUSE/RELAY PANEL
GENERATOR
GLOW PLUG IND
GLOW PLUG RELAY
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
IDLE AIR CONTROL SOLENOID (1995-96)
IGNITION
IGNITION D/8 E/2
IGNITION START SENSOR
IGNITION SWITCH
INJECTION
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM
J/C
LEFT FRONT DOOR CONTACT SWITCH
LOCK
NCA WIRE
PCV HEATING ELEMENT
POSITIONER
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
TWO-WAY EGR VALVE (1995-96)
WHT WIRE
Y/1
YEL/RED WIRE
Z/1
Go to component -> Wiring diagram engine performance 1.9l -> EGR PART THROTTLE SWITCH ENGINE COOLANT TEMPERATURE SENSOR
