Volkswagen Jetta III (1992-1998) driver's central locking system door switch Wiring diagram
This page shows the only wiring diagram for the component.driver's central locking system door switch, which is found in the car Volkswagen Jetta III (1992-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's central locking system door switch (1 of 1)
ALARM HORN
ALARM SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
ALARM SYSTEM INDICATOR LIGHT
BATTERY
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/WHT WIRE
D/8
DRIVER'S CENTRAL LOCKING SYSTEM DOOR SWITCH
F/1
FUSE/ RELAY PANEL (BEHIND LEFT SIDE OF DASH)
GRN WIRE
GRY WIRE
HOOD ALARM SWITCH
HOT AT ALL TIMES
IGNITION SWITCH
JUNCTION CONNECTOR (BEHIND FUSE/RELAY PANEL)
LEFT FRONT DOOR CONTACT SWITCH
LEFT REAR DOOR CONTACT SWITCH
LEFT TURN SIGNAL LAMPS
LOCK
LUGGAGE COMPARTMENT LID ALARM SWITCH
LUGGAGE COMPARTMENT LIGHT SWITCH
NCA WIRE
NOT USED
PASSENGER'S CENTRAL LOCKING SYSTEM DOOR SWITCH
POWER SUNROOF CONTROL MODULE
POWER WINDOWS, DOOR LOCKS SYSTEMS
RADIO
RED WIRE
RED/BLK WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT FRONT DOOR CONTACT SWITCH
RIGHT REAR DOOR CONTACT SWITCH
RIGHT TURN SIGNAL LAMPS
STARTING/CHARGING SYSTEM (STARTER)
WARNING SYSTEM (LEFT SEAT BELT SWITCH AND SEAT BELT WARNING SYSTEM RELAY)
WHT WIRE
Y/3
YEL WIRE
YEL/RED WIRE
