Volkswagen ID.4 I (2020-2024) Forced entry circuit

ANTI-THEFT SYSTEM BLU/WHT WIRE BRN WIRE BRN/YEL WIRE CENTRAL LOCKING SAFE INDICATOR LAMP CHILD SAFETY LOCK BUTTON COMPUTER DATA LINES SYSTEM DOORS CLOSED INDICATOR LAMP DRIVER DOOR CENTRAL LOCKING SAFE FUNCTION ACTUATOR DRIVER DOOR CENTRAL LOCKING SAFE MOTOR DRIVER DOOR CENTRAL LOCKING SYSTEM MOTOR DRIVER DOOR CONTACT SWITCH DRIVER DOOR CONTROL MODULE DRIVER DOOR LOCK UNIT DRIVER DOOR POWER WINDOW CONTROL HEAD DRIVER LOCK CYLINDER CONTACT SWITCH FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER INTERIOR LOCKING BUTTON FUSE 26 FUSE 9 FUSE PANEL C GRN/BLK WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES LEFT FRONT DOOR COUPLING POINT POWER WINDOWS SYSTEM PUSH BUTTON ILLUMINATION BULB REAR LID REMOTE RELEASE BUTTON RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR COUPLING POINT VIO WIRE VIO/WHT WIRE WHT WIRE YEL WIRE

ANTI-THEFT SYSTEM BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER SIDE REAR CENTRAL LOCKING SYSTEM ACTUATOR DRIVER SIDE REAR CENTRAL LOCKING SYSTEM MOTOR DRIVER SIDE REAR DOOR CENTRAL LOCKING SAFE MOTOR DRIVER SIDE REAR DOOR CONTACT SWITCH DRIVER SIDE REAR DOOR CONTROL MODULE DRIVER SIDE REAR DOOR LOCK UNIT FRONT PASSENGER CENTRAL LOCKING SAFE MOTOR FRONT PASSENGER DOOR CENTRAL LOCKING SAFE FUNCTION ACTUATOR FRONT PASSENGER DOOR CENTRAL LOCKING SYSTEM MOTOR FRONT PASSENGER DOOR CONTACT SWITCH FRONT PASSENGER DOOR LOCK UNIT GRY/YEL WIRE LEFT COUPLING POINT ON REAR LID LEFT REAR DOOR COUPLING POINT LUGGAGE COMPARTMENT LAMP SWITCH REAR LID CENTRAL LOCKING SYSTEM MOTOR REAR LID CONTACT SWITCH REAR LID HANDLE RELEASE BUTTON REAR LID LOCK UNIT RED/WHT WIRE RED/YEL WIRE VIO WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE YEL WIRE

ALARM HORN ANTI-THEFT ALARM SYSTEM SENSOR ANTI-THEFT SYSTEM BLU/WHT WIRE BLU/YEL WIRE BOTTOM LEFT COUPLING POINT IN INTERIOR BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM ENGINE HOOD CONTACT SWITCH FUSE 13 FUSE 40 FUSE 44 FUSE PANEL C GRN WIRE HOT AT ALL TIMES ORG/BRN WIRE PASSENGER SIDE REAR CENTRAL LOCKING SYSTEM ACTUATOR PASSENGER SIDE REAR CENTRAL LOCKING SYSTEM MOTOR PASSENGER SIDE REAR DOOR CENTRAL LOCKING SAFE MOTOR PASSENGER SIDE REAR DOOR CONTACT SWITCH PASSENGER SIDE REAR DOOR CONTROL MODULE PASSENGER SIDE REAR DOOR LOCK UNIT RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT REAR DOOR COUPLING POINT VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE
