Trunk & fuel door release circuit for Volkswagen ID.4 X I (2020-2024)

Trunk & fuel door release circuit (1 of 3)

ID.4 X Volkswagen I (2020-2024): Trunk & fuel door release circuit (1 of 3)

Get access

BLK/RED WIRE BLK/YEL WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COUPLING POINT ON RIGHT D-PILLAR DOOR LOCKS SYSTEM DRIVER DOOR CONTROL MODULE FUSE 37 FUSE PANEL C GRN WIRE GRN/BLK WIRE GRY WIRE HOT AT ALL TIMES LUGGAGE COMPARTMENT LAMP SWITCH ORG/BRN WIRE PUSH BUTTON ILLUMINATION BULB REAR LID CENTRAL LOCKING SYSTEM MOTOR REAR LID CONTACT SWITCH REAR LID CONTROL MODULE REAR LID DRIVE UNIT (TOP LEFT OF TAILGATE) REAR LID DRIVE UNIT 2 (TOP RIGHT OF TAILGATE) REAR LID LOCK UNIT REAR LID MOTOR 1 REAR LID MOTOR 1 SENSOR REAR LID MOTOR 2 REAR LID MOTOR 2 SENSOR REAR LID REMOTE RELEASE BUTTON RED WIRE RED/BLU WIRE RED/YEL WIRE WHT WIRE YEL/BLU WIRE YEL/GRN WIRE

Trunk & fuel door release circuit (2 of 3)

ID.4 X Volkswagen I (2020-2024): Trunk & fuel door release circuit (2 of 3)

Get access

BRN WIRE BRN/GRN WIRE COMPUTER DATA LINES SYSTEM FUSE 21 FUSE PANEL C GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/GRY WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE GRY/VIO WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT COUPLING POINT ON REAR LID ORG/BRN WIRE PERIPHERAL CAMERA CONTROL MODULE REAR LID CLOSING AID (LEFT SIDE OF TAILGATE) REAR LID CLOSING AID MOTOR REAR LID CLOSING AID/LOCK STOP SWITCH REAR LID HANDLE REAR LID HANDLE RELEASE BUTTON REAR LID WARNING BUZZER REAR PERIPHERAL CAMERA REAR VIEW CAMERA REAR VIEW CAMERA SYSTEM CONTROL MODULE RED/GRN WIRE RED/YEL WIRE WHT WIRE

Trunk & fuel door release circuit (3 of 3)

ID.4 X Volkswagen I (2020-2024): Trunk & fuel door release circuit (3 of 3)

Get access

BLK WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM COUPLING POINT ON RIGHT REAR BUMPER FUSE 18 FUSE PANEL C GRN WIRE GRY WIRE GRY/VIO WIRE HOT AT ALL TIMES ORG/BRN WIRE POWER REAR LID OPENING CONTROL MODULE POWER REAR LID OPENING SENSOR POWER REAR LID OPENING SENSOR 2 PUSH BUTTON ILLUMINATION BULB REAR LID CLOSING BUTTON REAR LID CONTROL HEAD RED/BLK WIRE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/BLK WIRE WHT WIRE
