Radio circuit, w/ amplifier for Volkswagen ID.4 X I (2020-2024)
Radio circuit, w/ amplifier (1 of 4)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
CENTER INSTRUMENT PANEL SWITCH MODULE
COMPUTER DATA LINES SYSTEM
ENGINE SOUND GENERATOR BUTTON
ENGINE SOUND GENERATOR INDICATOR LAMP
FRONT INFORMATION DISPLAY CONTROL HEAD
FUSE 20
FUSE 30
FUSE 46
FUSE PANEL C
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
ORG/ WIRE
ORG/BRN WIRE
PARALLEL PARKING ASSISTANCE BUTTON
PARALLEL PARKING ASSISTANCE INDICATOR LAMP
PARKING AID BUTTON
PARKING AID INDICATOR LAMP
RED WIRE
RED/BLU WIRE
VIO WIRE
WHT WIRE
WHT/RED WIRE
YEL/GRN WIRE
Radio circuit, w/ amplifier (2 of 4)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
CELLULAR TELEPHONE AMPLIFIER
DRIVER INFORMATION SYSTEM CONTROL MODULE W/ DISPLAY UNIT
GRN WIRE
GRN/WHT WIRE
GRY WIRE
MOBILE DEVICE CHARGER 1
ORG/ WIRE
PNK WIRE
RED/BLU WIRE
USB CONNECTION 1
W/ TRANSCEIVING STABILIZATION
WINDSHIELD PROJECTION HEAD UP DISPLAY CONTROL MODULE
YEL/GRN WIRE
Radio circuit, w/ amplifier (3 of 4)
BLK/BLU WIRE
BLK/RED WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
GRN WIRE
LEFT FRONT BASS SPEAKER
LEFT FRONT DOOR COUPLING POINT
LEFT FRONT TREBLE SPEAKER
ORG/BRN WIRE
PNK WIRE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RIGHT FRONT BASS SPEAKER
RIGHT FRONT DOOR COUPLING POINT
SUBWOOFER
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/GRN WIRE
Radio circuit, w/ amplifier (4 of 4)
ANTENNA
ANTENNA AMPLIFIER
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BRN/BLU WIRE
BRN/RED WIRE
DIGITAL RADIO ANTENNA
FUSE 14
FUSE PANEL C
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT REAR BASS SPEAKER
LEFT REAR DOOR COUPLING POINT
LEFT REAR TREBLE SPEAKER
NCA WIRE
RADIO ANTENNA 2
REAR WINDOW
RED WIRE
RED/GRN WIRE
RIGHT FRONT TREBLE SPEAKER
RIGHT REAR BASS SPEAKER
RIGHT REAR DOOR COUPLING POINT
RIGHT REAR TREBLE SPEAKER
ROOF ANTENNA SATELLITE TUNER ANTENNA
W/ DIGITAL RADIO
W/O DIGITAL RADIO
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
