Volkswagen ID.4 X I (2020-2024) transceiving stabilization control module Wiring diagram
This page shows the only wiring diagram for the component.transceiving stabilization control module, which is found in the car Volkswagen ID.4 X I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transceiving stabilization control module (1 of 1)
BRN WIRE
BRN/GRN WIRE
BURGLARY PROTECTION CONTROL MODULE 4
BURGLARY PROTECTION CONTROL MODULE 5
CENTER COUPLING POINT ON REAR LID
CHARGING SOCKET 1 LED MODULE
COUPLING POINT ON RIGHT REAR BUMPER
COUPLING POINT ON ROOF
DATA BUS ON BOARD DIAGNOSTIC INTERFACE
DIAGNOSTIC CONNECTION
DRIVER INFORMATION SYSTEM CONTROL MODULE W/ DISPLAY UNIT
ELECTRONIC DAMPING CONTROL MODULE
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
ENGINE SOUND GENERATOR MODULE 2
FROM LEFT REAR DOOR COUPLING POINT (DIAGRAM 4 OF 6)
FRONT INTERIOR LAMP
FRONT PASSENGER EXTERIOR REAR VIEW MIRROR
HIGH-MOUNTED BRAKE LAMP BULB
LANE CHANGE ASSISTANCE CONTROL MODULE
LANE CHANGE ASSISTANCE CONTROL MODULE 2
LEFT FOOTWELL LAMP
LEFT FRONT DOOR COUPLING POINT
LEFT REAR INTERIOR LAMP
LEFT VANITY MIRROR CONTACT SWITCH
MOBILE COMMUNICATION CONTROLLED ACCESS/START AUTHORIZATION SYSTEM CONTROL MODULE
PARKING AID CONTROL MODULE
PERIPHERAL CAMERA CONTROL MODULE
POWER REAR LID OPENING CONTROL MODULE
REAR FOG LAMP
REAR INTERIOR LAMP
REAR LID HANDLE
REAR VIEW CAMERA
RIGHT EXTERIOR REAR VIEW MIRROR LANE CHANGE ASSISTANCE WARNING LAMP
RIGHT FRONT DOOR COUPLING POINT
RIGHT LUGGAGE COMPARTMENT LAMP
RIGHT REAR INTERIOR LAMP
RIGHT TAIL LAMP
RIGHT VANITY MIRROR CONTACT SWITCH
SOCKETS RELAY
STEERING COLUMN ELECTRONICS CONTROL MODULE
TERMINAL 15 POWER SUPPLY RELAY
TRANSCEIVING STABILIZATION CONTROL MODULE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
W/ SUNROOF
Go to component -> Ground distribution circuit (5 of 6) -> TRANSCEIVING STABILIZATION CONTROL MODULE
