Volkswagen ID.4 Crozz I (2021-2024) Computer data lines circuit

BLK WIRE BLU WIRE BRN WIRE DATA BUS ON BOARD DIAGNOSTIC INTERFACE FUSE 41 FUSE 44 FUSE 60 FUSE PANEL C GRN WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED ORG/BRN WIRE ORG/GRN WIRE ORG/GRY WIRE PNK WIRE RED WIRE RED/BLK WIRE RED/GRY WIRE RED/WHT WIRE WHT WIRE

ACCESS/START AUTHORIZATION CONTROL MODULE BLK WIRE BLU WIRE BOTTOM RIGHT COUPLING POINT IN INTERIOR BURGLARY PROTECTION CONTROL MODULE 2 BURGLARY PROTECTION CONTROL MODULE 3 BURGLARY PROTECTION CONTROL MODULE 4 BURGLARY PROTECTION CONTROL MODULE 5 DIGITAL SOUND SYSTEM CONTROL MODULE DRIVER SIDE REAR DOOR CONTROL MODULE EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE GRN WIRE GRY WIRE INTERNET ACCESS CONTROL MODULE LEFT REAR DOOR COUPLING POINT ORG/BRN WIRE ORG/GRN WIRE ORG/GRY WIRE PNK WIRE REAR LID CONTROL MODULE ROOF SYSTEM CONTROL MODULE STEERING COLUMN ELECTRONICS CONTROL MODULE STEERING WHEEL) TOWING RECOGNITION CONTROL MODULE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE WHT WIRE

BLK WIRE BLU WIRE DRIVER ASSISTANCE SYSTEMS FRONT CAMERA ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE FRONT PASSENGER MEMORY SEAT CONTROL MODULE GRN WIRE GRY WIRE LANE CHANGE ASSISTANCE CONTROL MODULE LANE CHANGE ASSISTANCE CONTROL MODULE 2 LEFT FRONT DOOR COUPLING POINT LEFT FRONT SEAT COUPLING STATION MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE ORG/BRN WIRE ORG/GRN WIRE ORG/GRY WIRE PARKING AID CONTROL MODULE REAR PERIPHERAL CAMERA REAR VIEW CAMERA RIGHT FRONT SEAT COUPLING STATION W/ PERIPHERAL CAMERA W/O PERIPHERAL CAMERA WHT WIRE

ADAPTIVE CRUISE CONTROL MODULE BLK WIRE BLU WIRE BOTTOM LEFT COUPLING POINT IN INTERIOR COUPLING POINT IN LEFT FRONT DOOR COUPLING POINT IN RIGHT FRONT DOOR COUPLING POINT ON LEFT FRONT BUMPER DRIVER DOOR CONTROL MODULE DRIVER EXTERIOR REAR VIEW MIRROR ELECTRONIC DAMPING CONTROL MODULE ENGINE SOUND GENERATOR MODULE 1 FRONT PASSENGER EXTERIOR REAR VIEW MIRROR FRONT PERIPHERAL CAMERA GRN WIRE GRY WIRE LEFT FRONT HEADLAMP ORG/BRN WIRE ORG/GRN WIRE RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT HEADLAMP WHT WIRE

BATTERY REGULATION CONTROL MODULE BLK WIRE BLU WIRE DIGITAL SOUND SYSTEM CONTROL MODULE DRIVER INFORMATION SYSTEM CONTROL MODULE W/ DISPLAY UNIT DYNAMIC INFORMATION LIGHTING STRIP 3 ENGINE SOUND GENERATOR MODULE 2 FRONT INFORMATION DISPLAY CONTROL HEAD FRONT PASSENGER DOOR CONTROL MODULE GRN WIRE HEATING, AIR CONDITIONING CONTROL MODULE HIGH VOLTAGE BATTERY 1 HIGH-VOLTAGE BATTERY CHARGER 1 INFORMATION ELECTRONICS CONTROL MODULE 1 ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE PASSENGER SIDE REAR DOOR CONTROL MODULE RIGHT REAR DOOR COUPLING STATION VIO WIRE VOLTAGE CONVERTER W/ SOUND SYSTEM W/O SOUND SYSTEM WHT WIRE WINDSHIELD PROJECTION HEAD UP DISPLAY CONTROL MODULE

ABS CONTROL MODULE AIR BAG CONTROL MODULE BATTERY CONTROL MODULE BATTERY MODULE CONTROL MODULE 5 BATTERY MODULE CONTROL MODULE 9 BLK WIRE BLU WIRE BOTTOM RIGHT COUPLING POINT IN INTERIOR BRAKE BOOSTER ELECTRIC DRIVE POWER, CONTROL ELECTRONICS ELECTRIC DRIVE POWER, CONTROL ELECTRONICS 2 ENGINE/MOTOR CONTROL MODULE FRONT SUSPENSION COUPLING POINT ORG/BLU WIRE ORG/BRN WIRE ORG/WHT WIRE POWER STEERING CONTROL MODULE REAR SUSPENSION COUPLING POINT RIGHT END OF DASH) RWD STEERING COUPLING POINT 1 WHT WIRE
