Volkswagen Golf Mk8 (2019-2024) parallel parking assistance indicator lamp Wiring diagram
This page shows the only wiring diagram for the component.parallel parking assistance indicator lamp, which is found in the car Volkswagen Golf Mk8 (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram parallel parking assistance indicator lamp (1 of 1)
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
CENTER CONSOLE SWITCH MODULE 2
GRY WIRE
LEFT REAR CENTER PARKING AID SENSOR
LEFT REAR PARALLEL PARKING ASSISTANCE SENSOR
LEFT REAR PARKING AID SENSOR
PARALLEL PARKING ASSISTANCE BUTTON
PARALLEL PARKING ASSISTANCE INDICATOR LAMP
PARKING AID BUTTON
PARKING AID INDICATOR LAMP
PUSH BUTTON ILLUMINATION BULB
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT COUPLING POINT IN LUGGAGE COMPARTMENT
RIGHT REAR CENTER PARKING AID SENSOR
RIGHT REAR PARALLEL PARKING ASSISTANCE SENSOR
RIGHT REAR PARKING AID SENSOR
VIO/GRN WIRE
VIO/GRY WIRE
VIO/RED WIRE
Go to component -> Parking assistant circuit (2 of 2) -> PARALLEL PARKING ASSISTANCE INDICATOR LAMP
