Volkswagen Golf Mk8 (2019-2024) left front parallel parking assistance sensor Wiring diagram
This page shows the only wiring diagram for the component.left front parallel parking assistance sensor, which is found in the car Volkswagen Golf Mk8 (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front parallel parking assistance sensor (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FRONT PARKING AID WARNING BUZZER
FUSE 32
FUSE PANEL C
GRY WIRE
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
LEFT FRONT CENTER PARKING AID SENSOR
LEFT FRONT PARALLEL PARKING ASSISTANCE SENSOR
LEFT FRONT PARKING AID SENSOR
ORG/BRN WIRE
PARALLEL PARKING ASSISTANCE CONTROL MODULE/ PARKING AID CONTROL MODULE
REAR PARKING AID WARNING BUZZER
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT CENTER PARKING AID SENSOR
RIGHT FRONT PARALLEL PARKING ASSISTANCE SENSOR
RIGHT FRONT PARKING AID SENSOR
VIO WIRE
VIO/BLU WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/RED WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
Go to component -> Parking assistant circuit (1 of 2) -> LEFT FRONT PARALLEL PARKING ASSISTANCE SENSOR
