Volkswagen Golf Mk8 (2019-2024) cruise control set button, cruise control switch Wiring diagrams

1.4L TURBO 2.0L TURBO ACCELERATOR PEDAL MODULE ACCELERATOR PEDAL POSITION SENSOR ACCELERATOR PEDAL POSITION SENSOR 2 ANTI-LOCK BRAKES SYSTEM BLK WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BOTTOM LEFT COUPLING POINT IN INTERIOR BRAKE LAMP SWITCH BRAKE MASTER CYLINDER) BRN WIRE BRN/GRY WIRE BRN/RED WIRE CLUTCH POSITION SENSOR (M/T) (CLUTCH PEDAL ASSEMBLY) COMPUTER DATA LINES SYSTEM CRUISE CONTROL SET BUTTON, CRUISE CONTROL SWITCH ENGINE/ MOTOR CONTROL MODULE FUSE 21 FUSE 3 FUSE 6 FUSE PANEL B GRN WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED NCA WIRE ORG/BRN WIRE RED/GRN WIRE RED/YEL WIRE SENSOR 1 SENSOR 2 STARTING/ CHARGING SYSTEM STEERING COLUMN ELECTRONICS CONTROL MODULE VIO/BLU WIRE VIO/WHT WIRE W/O MULTI-FUNCTION STEERING WHEEL WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE

BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU/WHT WIRE BOTTOM LEFT COUPLING POINT IN INTERIOR BRN WIRE COMPUTER DATA LINES SYSTEM CRUISE CONTROL SET BUTTON, CRUISE CONTROL SWITCH DRIVER AIR BAG IGNITER ENGINE/MOTOR CONTROL MODULE GRN WIRE HORN SIGNAL ACTIVATION IGNITION/STARTER SWITCH NCA WIRE ORG/BRN WIRE ORG/GRN WIRE RED/WHT WIRE STEERING COLUMN ELECTRONICS CONTROL MODULE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/RED WIRE W/ CRUISE CONTROL
