Wiper/washer circuit for Volkswagen Golf Mk7 facelift (2017-2021)
Wiper/washer circuit
BLK/VIO WIRE
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
FUSE 19
FUSE 42
FUSE 47
FUSE 8
FUSE PANEL B
FUSE PANEL C
GRN/RED WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
HUMIDITY, RAIN, LIGHT RECOGNITION SENSOR
INSTRUMENT CLUSTER SYSTEM
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
REAR LID COUPLING POINT
REAR WINDOW WIPER MOTOR
RED/BLU WIRE
RED/WHT WIRE
STEERING COLUMN ELECTRONICS CONTROL MODULE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/WHT WIRE
VIO/YEL WIRE
WASHER FLUID RESERVOIR)
WHT WIRE
WINDSHIELD WASHER FLUID LEVEL SENSOR
WINDSHIELD WASHER PUMP
WINDSHIELD WIPER MOTOR
WIPER MOTOR CONTROL MODULE
