Trunk & fuel door release circuit for Volkswagen Golf Mk7 facelift (2017-2021)
Trunk & fuel door release circuit
BLK/BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
FUEL FILLER DOOR CENTRAL LOCKING ACTUATOR
FUSE 18
FUSE 26
FUSE PANEL C
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
INTERIOR REAR VIEW MIRROR
LUGGAGE COMPARTMENT LAMP
ORG/BRN WIRE
ORG/GRN WIRE
REAR LID CENTRAL LOCKING SYSTEM MOTOR
REAR LID COUPLING POINT
REAR LID HANDLE RELEASE BUTTON
REAR LID LOCK UNIT
REAR VIEW CAMERA
RED/BLU WIRE
RED/YEL WIRE
RIGHT TAIL LAMP 2
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
VIO/BLU WIRE
VIO/BRN WIRE
VIO/GRY WIRE
VIO/WHT WIRE
W/ REAR VIEW CAMERA
W/O HIGH BEAM ASSIST
W/O REAR VIEW CAMERA
WHT WIRE
