Radio circuit, w/o amplifier for Volkswagen Golf Mk7 facelift (2017-2021)
Radio circuit, w/o amplifier (1 of 3)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FRONT INFORMATION DISPLAY CONTROL HEAD
FUSE 10
FUSE 12
FUSE PANEL C
GPS ANTENNA
GRN WIRE
GSM ANTENNA
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT FRONT BASS SPEAKER
LEFT FRONT DOOR COUPLING POINT
LEFT FRONT TREBLE SPEAKER
MULTI-MEDIA SYSTEM CONTROL HEAD
ORG/ WIRE
ORG/BRN WIRE
ORG/VIO WIRE
RED WIRE
RED/YEL WIRE
ROOF ANTENNA
SATELLITE ANTENNA
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
Radio circuit, w/o amplifier (2 of 3)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
GRN WIRE
GRY WIRE
LEFT REAR BASS SPEAKER
LEFT REAR DOOR COUPLING POINT
LEFT REAR TREBLE SPEAKER
ORG/ WIRE
RADIO ANTENNA
RADIO ANTENNA 2
RED/GRN WIRE
RIGHT FRONT BASS SPEAKER
RIGHT FRONT DOOR COUPLING POINT
RIGHT FRONT TREBLE SPEAKER
RIGHT REAR BASS SPEAKER
RIGHT REAR DOOR COUPLING POINT
RIGHT REAR TREBLE SPEAKER
UPPER LEFT REAR WINDOW LEFT ANTENNA MODULE
UPPER RIGHT REAR WINDOW RIGHT ANTENNA MODULE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Radio circuit, w/o amplifier (3 of 3)
BLK WIRE
BLU WIRE
BRN WIRE
FUSE 16
FUSE PANEL C
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
NAVIGATION SYSTEM (EMERGENCY CALL CIRCUIT)
NAVIGATION SYSTEM (REAR VIEW CAMERA CIRCUIT)
ORG/ WIRE
RED WIRE
RED/BLU WIRE
TELEPHONE MICROPHONE
USB CONNECTION 1
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
