Power windows circuit for Volkswagen Golf Mk7 facelift (2017-2021)
Power windows circuit (1 of 2)
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE
DRIVER DOOR POWER WINDOW CONTROL HEAD
DRIVER POWER WINDOW BUTTON
DRIVER SIDE REAR POWER WINDOW BUTTON
FRONT PASSENGER POWER WINDOW BUTTON
FUSE 25
FUSE 39
FUSE PANEL C
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR COUPLING POINT
LEFT REAR DOOR COUPLING POINT
LEFT REAR WINDOW REGULATOR MOTOR
LEFT WINDOW REGULATOR MOTOR
ORG/BRN WIRE
ORG/GRN WIRE
PASSENGER SIDE REAR POWER WINDOW BUTTON
PUSH BUTTON ILLUMINATION BULB
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
Power windows circuit (2 of 2)
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER POWER WINDOW BUTTON
GRY WIRE
MIRROR ADJUSTMENT SWITCH ILLUMINATION BULB
ORG/BRN WIRE
ORG/GRN WIRE
PASSENGER SIDE REAR POWER WINDOW BUTTON
PUSH BUTTON ILLUMINATION BULB
RED WIRE
RED/YEL WIRE
RIGHT FRONT DOOR COUPLING POINT
RIGHT REAR DOOR COUPLING POINT
RIGHT REAR WINDOW REGULATOR MOTOR
RIGHT WINDOW REGULATOR MOTOR
VIO/WHT WIRE
WHT WIRE
