Power seats circuit for Volkswagen Golf Mk7 facelift (2017-2021)
Power seats circuit
ANGLE ADJUSTMENT BUTTON
BACKREST ADJUSTMENT BUTTON
BLK WIRE
BLU WIRE
BRN WIRE
COUPLING STATION IN LEFT FRONT SEAT
COUPLING STATION IN RIGHT FRONT SEAT
DRIVER BACKREST ADJUSTMENT MOTOR
DRIVER SEAT ADJUSTMENT CONTROL HEAD
DRIVER SEAT ANGLE ADJUSTMENT MOTOR
DRIVER SEAT FORWARD/BACK ADJUSTMENT MOTOR
DRIVER SEAT HEIGHT ADJUSTMENT MOTOR
FRONT PASSENGER BACKREST ADJUSTMENT MOTOR
FRONT PASSENGER SEAT ADJUSTMENT CONTROL HEAD
FUSE 45
FUSE PANEL C
GRN WIRE
HOT AT ALL TIMES
LEFT FRONT SEAT COUPLING STATION
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RIGHT FRONT SEAT COUPLING STATION
SEAT FORWARD/BACK ADJUSTMENT BUTTON
SEAT HEIGHT ADJUSTMENT BUTTON
VIO WIRE
W/ HEATED SEATS
W/O HEATED SEATS
