Blind spot monitoring circuit for Volkswagen Golf Mk7 facelift (2017-2021)
Blind spot monitoring circuit
BLIND SPOT DETECTION CONTROL MODULE
BLIND SPOT DETECTION CONTROL MODULE 2
BLIND SPOT DETECTION WARNING LAMP
BLK/GRN WIRE
BRN WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 32
FUSE PANEL C
GRN WIRE
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
LEFT EXTERIOR REAR VIEW MIRROR
LEFT FRONT DOOR COUPLING POINT
ORG/BRN WIRE
ORG/GRY WIRE
ORG/RED WIRE
RED/GRN WIRE
RIGHT EXTERIOR REAR VIEW MIRROR
RIGHT FRONT DOOR COUPLING POINT
YEL WIRE
