Courtesy lamps circuit for Volkswagen Golf Mk7 facelift (2017-2021)

BLK/GRN WIRE BLU/GRN WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COUPLING POINT ON ROOF DRIVER VANITY MIRROR LAMP DRIVER VANITY MIRROR LAMP CONTACT SWITCH FRONT INTERIOR LAMP FRONT PASSENGER VANITY MIRROR LAMP FRONT PASSENGER VANITY MIRROR LAMP CONTACT SWITCH FUSE 25 FUSE 39 FUSE 4 FUSE PANEL C GLOVE COMPARTMENT LAMP GLOVE COMPARTMENT LAMP SWITCH GRN/GRY WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT ILLUMINATION CIRCUIT INTERIOR MONITORING, VEHICLE INCLINATION DEACTIVATION BUTTON INTERIOR REAR VIEW MIRROR LEFT FRONT DOOR COUPLING POINT LEFT FRONT FOOTWELL LAMP LEFT REAR DOOR CONTACT SWITCH LEFT REAR DOOR COUPLING POINT LEFT REAR DOOR LOCK UNIT LUGGAGE COMPARTMENT LAMP ORG/BRN WIRE ORG/GRN WIRE REAR INTERIOR LAMP REAR LID COUPLING POINT REAR LID LOCK UNIT RED/BLU WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT FOOTWELL LAMP RIGHT REAR DOOR CONTACT SWITCH RIGHT REAR DOOR COUPLING POINT RIGHT REAR DOOR LOCK UNIT VEHICLE ELECTRICAL SYSTEM CONTROL MODULE W/ HIGH BEAM ASSIST WHT WIRE YEL/BLU WIRE YEL/VIO WIRE

BLK/BLU WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM DOOR CONTACT SWITCH DRIVER DOOR CONTROL MODULE DRIVER DOOR LOCK UNIT DRIVER ENTRY LAMP DRIVER EXTERIOR REAR VIEW MIRROR DRIVER SIDE INTERIOR DOOR HANDLE ILLUMINATION LAMP FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER DOOR LOCK UNIT FRONT PASSENGER ENTRY LAMP FRONT PASSENGER EXTERIOR REAR VIEW MIRROR GRN WIRE GRN/WHT WIRE INSTRUMENT ILLUMINATION CIRCUIT LEFT FRONT DOOR COUPLING POINT LEFT FRONT SILL PANEL AMBIENT LIGHTING FIBER OPTIC CABLE ORG/BRN WIRE ORG/GRN WIRE PASSENGER SIDE INTERIOR DOOR HANDLE ILLUMINATION LAMP RED/YEL WIRE RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT SILL PANEL AMBIENT LIGHTING FIBER OPTIC CABLE VIO/BLU WIRE WHT WIRE
