Backup lamps circuit for Volkswagen Golf Mk7 facelift (2017-2021)
Backup lamps circuit
AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR
BACKUP LAMP SWITCH
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DUAL-CLUTCH TRANSMISSION MECHATRONIC
FUSE 24
FUSE 34
FUSE PANEL C
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
INTERIOR REAR VIEW MIRROR
LEFT BACKUP LAMP BULB
LEFT TAIL LAMP 2
M/T
ORG/BRN WIRE
ORG/GRN WIRE
REAR LID COUPLING POINT
REAR VIEW CAMERA
RED WIRE
RIGHT BACKUP LAMP BULB
RIGHT TAIL LAMP 2
SELECTOR LEVER
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
WHT WIRE
YEL WIRE
