Anti-lock brakes circuit, w/o adaptive cruise control for Volkswagen Golf Mk7 facelift (2017-2021)

2.0L TURBO, 1.4L TURBO ABS CONTROL MODULE (RIGHT REAR OF ENGINE COMPT) ABS HYDRAULIC PUMP BLK WIRE BLK/RED WIRE BLK/VIO WIRE BLU WIRE BLU/RED WIRE BOTTOM LEFT COUPLING POINT IN INTERIOR BRAKE LAMP SWITCH BRAKE MASTER CYLINDER) BRAKE PRESSURE SENSOR 1 BRN WIRE COMPUTER DATA LINES SYSTEM DRIVING DYNAMICS REGULATION SWITCH VALVE 1 DRIVING DYNAMICS REGULATION SWITCH VALVE 2 ENGINE/MOTOR CONTROL MODULE FUSE 1 FUSE 17 FUSE 2 FUSE 6 FUSE PANEL B GRN WIRE GRN/WHT WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ MOTRONIC ENGINE CONTROL MODULE SUPPLY RELAY ENERGIZED LEFT FRONT ABS INLET VALVE LEFT FRONT ABS OUTLET VALVE LEFT FRONT ABS WHEEL SPEED SENSOR LEFT REAR ABS INLET VALVE LEFT REAR ABS OUTLET VALVE LEFT REAR ABS WHEEL SPEED SENSOR LONGITUDINAL ACCELERATION SENSOR ORG/BRN WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT ABS INLET VALVE RIGHT FRONT ABS OUTLET VALVE RIGHT REAR ABS INLET VALVE RIGHT REAR ABS OUTLET VALVE ROTATION RATE SENSOR VIO/GRN WIRE WHT WIRE

ABS INDICATOR LAMP ASR/ESP BUTTON ASR/ESP INDICATOR LAMP BLK WIRE BLK/YEL WIRE BLU WIRE BLU/BRN WIRE BRAKE FLUID LEVEL WARNING SWITCH BRAKE PAD WEAR INDICATOR LAMP BRAKE SYSTEM INDICATOR LAMP BRN WIRE CENTER CONSOLE SWITCH MODULE 1 CENTER CONSOLE SWITCH MODULE 2 COMPUTER DATA LINES SYSTEM FUSE 17 FUSE 26 FUSE 34 FUSE PANEL C GRN WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE ORG/BRN WIRE ORG/GRN WIRE PARKING BRAKE INDICATOR LAMP RED/GRN WIRE RED/YEL WIRE RIGHT FRONT ABS WHEEL SPEED SENSOR RIGHT FRONT BRAKE PAD WEAR SENSOR RIGHT REAR ABS WHEEL SPEED SENSOR TIRE PRESSURE MONITORING BUTTON TIRE PRESSURE MONITORING DISPLAY INDICATOR LAMP VACUUM SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/GRN WIRE YEL WIRE
