Volkswagen Golf Mk7 facelift (2017-2021) upper right rear window right antenna module Wiring diagrams

This page contains all the electrical diagrams for the component. upper right rear window right antenna module, in which he is found in the car Volkswagen Golf Mk7 facelift (2017-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

upper right rear window right antenna module wiring diagram (1 of 4)

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE GRN WIRE GRN/WHT WIRE GRY WIRE ORG/ WIRE RADIO ANTENNA RADIO ANTENNA 2 RED/GRN WIRE RED/VIO WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT TREBLE SPEAKER RIGHT REAR BASS SPEAKER RIGHT REAR DOOR COUPLING POINT RIGHT REAR TREBLE SPEAKER UPPER LEFT REAR WINDOW LEFT ANTENNA MODULE UPPER RIGHT REAR WINDOW RIGHT ANTENNA MODULE WHT WIRE YEL WIRE

Go to component -> Navigation circuit, w/ amplifier (3 of 4) -> UPPER RIGHT REAR WINDOW RIGHT ANTENNA MODULE

upper right rear window right antenna module wiring diagram (2 of 4)

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE GRN WIRE GRY WIRE LEFT REAR BASS SPEAKER LEFT REAR DOOR COUPLING POINT LEFT REAR TREBLE SPEAKER ORG/ WIRE RADIO ANTENNA RADIO ANTENNA 2 RED/GRN WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT TREBLE SPEAKER RIGHT REAR BASS SPEAKER RIGHT REAR DOOR COUPLING POINT RIGHT REAR TREBLE SPEAKER UPPER LEFT REAR WINDOW LEFT ANTENNA MODULE UPPER RIGHT REAR WINDOW RIGHT ANTENNA MODULE WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Navigation circuit, w/o amplifier (2 of 3) -> UPPER RIGHT REAR WINDOW RIGHT ANTENNA MODULE
