Volkswagen Golf Mk7 facelift (2017-2021) horizontal position sensor vertical position sensor Wiring diagram
This page shows the only wiring diagram for the component.horizontal position sensor vertical position sensor, which is found in the car Volkswagen Golf Mk7 facelift (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram horizontal position sensor vertical position sensor (1 of 1)
BLIND SPOT DETECTION WARNING LAMP
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DRIVER DOOR CONTROL MODULE
DRIVER EXTERIOR REAR VIEW MIRROR
DRIVER MIRROR ADJUSTMENT MOTOR
DRIVER MIRROR ADJUSTMENT MOTOR 2
ENTRY LAMP
EXTERIOR REAR VIEW MIRROR ADJUSTER
EXTERIOR REAR VIEW MIRROR HEATING SWITCH
FOLDING MOTOR
GRN WIRE
GRY WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HEATER
HORIZONTAL POSITION SENSOR VERTICAL POSITION SENSOR
MIRROR ADJUSTING SWITCH
MIRROR ADJUSTMENT SWITCH ILLUMINATION BULB
MIRROR FOLDING SWITCH
MIRROR SELECTOR SWITCH
NAVIGATION SYSTEM
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
TURN SIGNAL BULB
VIO WIRE
W/ AUTOMATIC MIRROR ADJUSTMENT
W/O AUTOMATIC MIRROR ADJUSTMENT
WHT WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Power mirrors circuit (1 of 2) -> HORIZONTAL POSITION SENSOR VERTICAL POSITION SENSOR
