Electronic suspension circuit for Volkswagen Golf Mk7 (2012-2017)

BLK WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM ELECTRONIC DAMPING CONTROL MODULE FUSE 13 FUSE PANEL C GRN/BRN WIRE GRN/GRY WIRE GRY WIRE GRY/BLK WIRE GRY/BRN WIRE HOT AT ALL TIMES LEFT "C" PILLAR) LEFT BOTTOM INTERIOR COUPLING POINT LEFT FRONT BODY ACCELERATION SENSOR LEFT FRONT DAMPING ADJUSTMENT VALVE LEFT FRONT LEVEL CONTROL SYSTEM SENSOR LEFT REAR DAMPING ADJUSTMENT VALVE LEFT REAR LEVEL CONTROL SYSTEM SENSOR ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE REAR BODY ACCELERATION SENSOR RED WIRE RED/YEL WIRE RIGHT FRONT BODY ACCELERATION SENSOR RIGHT FRONT DAMPING ADJUSTMENT VALVE RIGHT FRONT LEVEL CONTROL SYSTEM SENSOR RIGHT REAR DAMPING ADJUSTMENT VALVE SELECTOR LEVER VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/GRN WIRE VIO/YEL WIRE WHT/BLU WIRE WHT/GRY WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE
