Volkswagen Golf Mk7 (2012-2017) selector lever transmission range position display unit Wiring diagram
This page shows the only wiring diagram for the component.selector lever transmission range position display unit, which is found in the car Volkswagen Golf Mk7 (2012-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram selector lever transmission range position display unit (1 of 1)
1.8L TURBO, 2.0L TURBO
2.0L TURBO DIESEL
BLK/RED WIRE
BLK/VIO WIRE
BLU/VIO WIRE
BRAKE LAMP SWITCH (BRAKE MASTER CYLINDER)
BRN WIRE
BRN/BLU WIRE
COMPUTER
COMPUTER DATA LINES SYSTEM
DATA LINES
ELECTRONIC DAMPING CONTROL MODULE
ENERGIZED (1.8L TURBO, 2.0L TURBO)
ENGINE CONTROL MODULE
FUSE 6
FUSE 7
FUSE PANEL B
FUSE PANEL C
GRY WIRE
GRY/RED WIRE
HATCHBACK
HOT AT ALL TIMES
HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED
HOT W/ TERMINAL 30 POWER SUPPLY RELAY
INSTRUMENT CLUSTER
LEFT "C" PILLAR)
LEFT COUPLING POINT IN ENGINE COMPARTMENT
MULTI-FUNCTION STEERING WHEEL CONTROL MODULE
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED/YEL WIRE
RIGHT MULTI-FUNCTION STEERING WHEEL BUTTON
SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT
SELECTOR SWITCH
SHIFT LOCK SOLENOID, SELECTOR LEVER PARK POSITION LOCK SWITCH
STEERING COLUMN ASSEMBLY
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE
SYSTEM
TIPTRONIC DOWNSHIFT BUTTON
TIPTRONIC UPSHIFT BUTTON
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/WHT WIRE
WAGON
WHT WIRE
Go to component -> A/t circuit (2 of 2) -> SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT
