Volkswagen Golf Mk7 (2012-2017) multi-function transmission range switch Wiring diagram
This page shows the only wiring diagram for the component.multi-function transmission range switch, which is found in the car Volkswagen Golf Mk7 (2012-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram multi-function transmission range switch (1 of 1)
1.8L TURBO, 2.0L TURBO 2.0L TURBO DIESEL WAGON HATCHBACK
2.0L TURBO DIESEL
BLK/RED WIRE
BLK/VIO WIRE
BLU/VIO WIRE
BRAKE LAMP SWITCH (BRAKE MASTER CYLINDER)
BRN WIRE
CLUTCH POSITION SENSOR (CLUTCH PEDAL ASSEMBLY)
COMPUTER DATA LINES SYSTEM
DSG TRANSMISSION MECHATRONIC
ELECTRONIC DAMPING CONTROL MODULE
ENERGIZED (EXCEPT 2.0L TURBO DIESEL)
ENGINE CONTROL MODULE (ECM)
FUSE 13
FUSE 6
FUSE 7
FUSE PANEL B
FUSE PANEL C
GRN/YEL WIRE
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED
HOT W/ TERMINAL 30 POWER SUPPLY RELAY
IGNITION SWITCH KEY LOCK SOLENOID
IGNITION/ STARTER SWITCH
INSTRUMENT CLUSTER
LEFT "C" PILLAR)
MULTI-FUNCTION TRANSMISSION RANGE SWITCH
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED/YEL WIRE
SELECTOR LEVER
SELECTOR LEVER TRANSMISSION POSITION DISPLAY UNIT
SHIFT LOCK SOLENOID, SELECTOR LEVER PARK POSITION LOCK SWITCH
STEERING COLUMN ASSEMBLY
STEERING COLUMN ELECTRONICS CONTROL MODULE
TRANSMISSION CONTROL MODULE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/GRY WIRE
Go to component -> Shift interlock circuit -> MULTI-FUNCTION TRANSMISSION RANGE SWITCH
