Backup lamps circuit, m/t for Volkswagen Golf Mk6 (2008-2012)
Backup lamps circuit, m/t
AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR
BACKUP LIGHT SWITCH
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRY/WHT WIRE
LEFT BACKUP LAMP/ LEFT REAR FOG LAMP
ORG/BRN WIRE
ORG/GRN WIRE
RIGHT BACKUP LAMP/ RIGHT REAR FOG LAMP
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT SIDE OF DASH)
WHT WIRE
