Volkswagen Golf Mk6 (2008-2012) Electronic power steering circuit

28 29 COMPUTER DATA LINES SYSTEM BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ELECTRO- MECHANICAL POWER STEERING INDICATOR LAMP ELECTRO- MECHANICAL POWER STEERING MOTOR FUSE 2 (LEFT SIDE OF DASH) FUSE PANEL C GRN WIRE HOT AT ALL TIMES FUSE PANEL A FUSE 2 HOT W/ POWER SUPPLY RELAY (TERMINAL 50) ENERGIZED INSTRUMENT CLUSTER CONTROL MODULE ORG/BLK WIRE ORG/BRN WIRE POWER STEERING CONTROL MODULE (FRONT SUBFRAME) RED WIRE STEERING ANGLE SENSOR STEERING TORQUE SENSOR VIO WIRE WHT WIRE YEL WIRE
