Steering column electronic systems control module circuit, late production for Volkswagen Golf Mk6 (2008-2012)

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/VIO WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CRUISE CONTROL SET BUTTON (IF EQUIPPED) CRUISE CONTROL SWITCH (IF EQUIPPED) CRUISE CONTROL SWITCH, CRUISE CONTROL SET-BUTTON ENGINE CONTROLS SYSTEM GRN WIRE GRY WIRE HORNS SYSTEM MULTI- FUNCTION SWITCH MULTI-FUNCTION INDICATOR MEMORY SWITCH (W/ MULTI-FUNCTION DISPLAY) MULTI-FUNCTION INDICATOR SELECTION SWITCH (W/ MULTI-FUNCTION DISPLAY) NCA WIRE ORG/BRN WIRE ORG/GRN WIRE REAR WINDOW WIPER SWITCH, WINDSHIELD, HEADLAMP WASHER PUMP SWITCH RED WIRE RED/BLK WIRE RED/BRN WIRE RED/YEL WIRE SHIFT INTERLOCK SYSTEM SHIFT INTERLOCK, TRANSMISSIONS SYSTEMS STARTING/CHARGING SYSTEM STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (STEERING COLUMN) SUPPLEMENTAL RESTRAINTS SYSTEM TURN SIGNAL SWITCH, HEADLIGHT DIMMER/ FLASHER SWITCH VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT SIDE OF DASH) VIO WIRE W/ MULTIFUCTION W/O MULTIFUCTION WINDSHIELD WIPER INTERMITTENT MODE SWITCH WINDSHIELD WIPER INTERMITTENT REGULATOR YEL WIRE

BLK WIRE BLK/WHT WIRE BLOCKING DIODE FUSE FUSE PANEL GRY WIRE HORNS SYSTEM HOT AT ALL TIMES LEFT MULTI-FUNCTION BUTTONS MULTI-FUNCTION STEERING WHEEL CONTROL MODULE RED WIRE RED/BLK WIRE RED/YEL WIRE RIGHT MULTI-FUNCTION BUTTONS TIPTRONIC DOWNSHIFT BUTTON TIPTRONIC UPSHIFT BUTTON W/O START/STOP SYSTEM
