Volkswagen Golf Mk6 (2008-2012) tire pressure monitor- ing display button Wiring diagram
This page shows the only wiring diagram for the component.tire pressure monitor- ing display button, which is found in the car Volkswagen Golf Mk6 (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tire pressure monitor- ing display button (1 of 1)
ASR/ESP SWITCH
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/GRN WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRY WIRE
GRY/RED WIRE
LEFT FRONT ABS WHEEL SPEED SENSOR (LEFT FRONT WHEEL HUB)
LEFT REAR ABS WHEEL SPEED SENSOR (LEFT REAR WHEEL HUB)
ORG/BRN WIRE
ORG/GRN WIRE
RED/BRN WIRE
RIGHT FRONT ABS WHEEL
RIGHT REAR ABS WHEEL SPEED SENSOR
SPEED SENSOR (RIGHT FRONT WHEEL HUB)
TIRE PRESSURE MONITOR- ING DISPLAY BUTTON
VACUUM SENSOR
VIO/GRN WIRE
Go to component -> Anti-lock brakes circuit, with esp (2 of 2) -> TIRE PRESSURE MONITOR- ING DISPLAY BUTTON
