Volkswagen Golf Mk6 (2008-2012) steering column electronics control module Wiring diagram
This page shows the only wiring diagram for the component.steering column electronics control module, which is found in the car Volkswagen Golf Mk6 (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering column electronics control module (1 of 1)
BATTERY
BLK WIRE
BLU WIRE
BRN WIRE
CHARGING CIRCUIT
COMPUTER DATA LINES SYSTEM
FUSE 2
FUSE PANEL C (LEFT SIDE OF DASH)
GRN WIRE
GRY WIRE
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
IGNITION/STARTER SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
POWER SUPPLY RELAY
RED WIRE
RED/BLK WIRE
STARTER
STEERING COLUMN ELECTRONICS CONTROL MODULE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT SIDE OF DASH)
VIO WIRE
YEL WIRE
Go to component -> Starting circuit -> STEERING COLUMN ELECTRONICS CONTROL MODULE
