Volkswagen Golf Mk6 (2008-2012) right daytime running lamp, right front positioning lamp Wiring diagram
This page shows the only wiring diagram for the component.right daytime running lamp, right front positioning lamp, which is found in the car Volkswagen Golf Mk6 (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right daytime running lamp, right front positioning lamp (1 of 1)
2.5L 2.0L TURBO
A/C COMPRESSOR REGULATOR VALVE
AUTOMATIC GLOW TIME CONTROL MODULE
AUXILIARY HEATER CONTROL MODULE
BLK WIRE
BRAKE FLUID LEVEL WARNING SWITCH
BRN WIRE
BRN/BLK WIRE
DSG TRANSMISSION MECHATRONIC
ENGINE HOOD CONTACT SWITCH
FUEL PUMP 2
GRN/YEL WIRE
HEADLAMP RANGE/ CORNERING LAMP CONTROL MODULE
HEADLAMP WASHER PUMP
HEATER COOLANT SHUT-OFF VALVE
HIGH TONE HORN
LEFT DAYTIME RUNNING LAMP, PARKING LAMP BULB
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLAMP POWER OUTPUT STAGE
LEFT HEADLIGHT
LEFT HID HEADLAMP BULB
LEFT HIGH LEFT SIDE BEAM HEADLAMP BULB
LEFT LOW BEAM HEADLAMP BULB
LEFT LOW BEAM REFLECTOR MOTOR
LEFT PARKING LAMP, LEFT DAYTIME RUNNING LAMP
LOW TONE HORN
MARKER LAMP BULB
MULITI-FUNCTION TRANSMISSION RANGE SWITCH
NCA WIRE
RIGHT DAYTIME RUNNING LAMP, RIGHT FRONT POSITIONING LAMP
RIGHT FRONT FOG LAMP BULB, RIGHT CORNERING LAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP POWER OUTPUT STAGE
RIGHT HEADLIGHT
RIGHT HID HEADLAMP BULB
RIGHT HIGH BEAM HEADLAMP BULB
RIGHT LOW BEAM HEADLAMP BULB
RIGHT LOW BEAM REFLECTOR MOTOR
RIGHT PARKING LAMP, RIGHT DAYTIME RUNNING LAMP
RIGHT SIDE MARKER LAMP BULB
TRANSMISSION CONTROL MODULE
Go to component -> Ground distribution circuit, early production (3 of 4) -> RIGHT DAYTIME RUNNING LAMP, RIGHT FRONT POSITIONING LAMP
