Volkswagen Golf Mk6 (2008-2012) left headlamp power output stage Wiring diagrams
This page contains all the electrical diagrams for the component. left headlamp power output stage, in which he is found in the car Volkswagen Golf Mk6 (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
left headlamp power output stage wiring diagram (1 of 4)
2.5L 2.0L TURBO
A/C COMPRESSOR REGULATOR VALVE
AUTOMATIC GLOW TIME CONTROL MODULE
AUXILIARY HEATER CONTROL MODULE
BLK WIRE
BRAKE FLUID LEVEL WARNING SWITCH
BRN WIRE
BRN/BLK WIRE
DSG TRANSMISSION MECHATRONIC
ENGINE HOOD CONTACT SWITCH
FUEL PUMP 2
GRN/YEL WIRE
HEADLAMP RANGE/ CORNERING LAMP CONTROL MODULE
HEADLAMP WASHER PUMP
HEATER COOLANT SHUT-OFF VALVE
HIGH TONE HORN
LEFT DAYTIME RUNNING LAMP, PARKING LAMP BULB
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLAMP POWER OUTPUT STAGE
LEFT HEADLIGHT
LEFT HID HEADLAMP BULB
LEFT HIGH LEFT SIDE BEAM HEADLAMP BULB
LEFT LOW BEAM HEADLAMP BULB
LEFT LOW BEAM REFLECTOR MOTOR
LEFT PARKING LAMP, LEFT DAYTIME RUNNING LAMP
LOW TONE HORN
MARKER LAMP BULB
MULITI-FUNCTION TRANSMISSION RANGE SWITCH
NCA WIRE
RIGHT DAYTIME RUNNING LAMP, RIGHT FRONT POSITIONING LAMP
RIGHT FRONT FOG LAMP BULB, RIGHT CORNERING LAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP POWER OUTPUT STAGE
RIGHT HEADLIGHT
RIGHT HID HEADLAMP BULB
RIGHT HIGH BEAM HEADLAMP BULB
RIGHT LOW BEAM HEADLAMP BULB
RIGHT LOW BEAM REFLECTOR MOTOR
RIGHT PARKING LAMP, RIGHT DAYTIME RUNNING LAMP
RIGHT SIDE MARKER LAMP BULB
TRANSMISSION CONTROL MODULE
Go to component -> Ground distribution circuit, early production (3 of 4) -> LEFT HEADLAMP POWER OUTPUT STAGE
left headlamp power output stage wiring diagram (2 of 4)
2.5L 2.0L TURBO
ALARM HORN
AUTOMATIC A/C GLOW TIME COMPRESSOR CONTROL REGULATOR MODULE VALVE
AUXILIARY HEATER CONTROL MODULE
BLK WIRE
BRAKE FLUID LEVEL WARNING SWITCH
BRN WIRE
BRN/BLK WIRE
ENGINE HOOD CONTACT SWITCH
FUEL PUMP 2
GRN/YEL WIRE
HEADLAMP LEFT LOW RANGE/ BEAM CORNERING REFLECTOR LAMP CONTROL MOTOR MODULE
HEADLAMP RANGE/ CORNERING LAMP CONTROL MODULE
HEADLAMP WASHER PUMP
HEATER COOLANT SHUT-OFF VALVE
HIGH TONE HORN
LEFT ADAPTIVE CORNERING LAMP MOTOR
LEFT FRONT TURN SIGNAL BULB
LEFT HEADLAMP POWER OUTPUT STAGE
LEFT HEADLIGHT
LEFT HID HEADLAMP MULITI-FUNCTION CONTROL TRANSMISSION MODULE RANGE SWITCH
LEFT LOW BEAM HEADLAMP BULB
LEFT PARKING LAMP, LEFT DAYTIME RUNNING LAMP
LOW TONE HORN
NCA WIRE
RIGHT DAY- TIME RUNNING LAMPS, RIGHT HIGH BEAM HEADLAMP BULB
RIGHT DAYTIME RUNNING LAMP, PARKING LAMP CONTROL MODULE
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP POWER OUTPUT STAGE
RIGHT HEADLIGHT
RIGHT HID HEADLAMP CONTROL MODULE
RIGHT HIGH BEAM HEADLAMP BULB
RIGHT LOW BEAM HEADLAMP BULB
RIGHT LOW BEAM REFLECTOR MOTOR
RIGHT RIGHT SIDE FRONT MARKER TURN LAMP SIGNAL BULB BULB
RIGHT SIDE MARKER LAMP BULB
SENSOR FOR RIGHT VARIABLE HEADLAMP POSITIONING MOTOR
TRANSMISSION CONTROL MODULE
WIPER MOTOR CONTROL MODULE
Go to component -> Ground distribution circuit, late production (3 of 4) -> LEFT HEADLAMP POWER OUTPUT STAGE
left headlamp power output stage wiring diagram (3 of 4)
BLK WIRE
BLK/RED WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 5 FUSE 6
FUSE PANEL C (LEFT SIDE OF DASH)
HIGH BEAM INDICATOR
HOT W/ POWER SUPPLY RELAY 2 (TERMINAL 15) ENERGIZED
INSTRUMENT CLUSTER CONTROL MODULE
LEFT ADAPTIVE CORNERING LAMP MOTOR
LEFT ADAPTIVE CORNERING LAMP MOTOR 2 3 4 6 5 1
LEFT DAYTIME RUNNING LAMP, PARKING LAMP CONTROL MODULE
LEFT DAYTIME RUNNING LAMP, PARKING LAMP LED MODULE
LEFT DAYTIME RUNNING LAMP, PARKING LAMP LED MODULE, TEMPERATURE SENSOR
LEFT HEADLAMP BEAM ADJUSTMENT MOTOR
LEFT HEADLAMP POWER OUTPUT STAGE
LEFT HEADLIGHT
LEFT LOW BEAM HEADLAMP REFLECTOR MOTOR
LEFT SWIVEL MODULE 1 2 3 POSITION SENSOR
LEFT VARIABLE HEADLAMP POSITIONING MOTOR SENSOR
REAR FOG LAMP INDICATOR
RIGHT DAYTIME RUNNING LAMP, PARKING LAMP CONTROL MODULE
RIGHT DAYTIME RUNNING LAMP, PARKING LAMP LED MODULE
RIGHT DAYTIME RUNNING LAMP, PARKING LAMP LED MODULE, TEMPERATURE SENSOR
RIGHT HEADLAMP BEAM ADJUSTMENT MOTOR
RIGHT HEADLAMP POWER OUTPUT STAGE
RIGHT HEADLIGHT
RIGHT LOW BEAM HEADLAMP REFLECTOR MOTOR
RIGHT SWIVEL MODULE POSITION SENSOR
RIGHT VARIABLE HEADLAMP POSITIONING MOTOR SENSOR
YEL WIRE
Go to component -> Headlights circuit, late production with hid headlamps (2 of 2) -> LEFT HEADLAMP POWER OUTPUT STAGE
left headlamp power output stage wiring diagram (4 of 4)
ABS BRAKE CONTROL LIGHT MODULE SWITCH (2.5L, 2.0L DUAL CLUTCH TRANSMISSION)
AIR BAG FRONT CONTROL PASSENGER'S MODULE AIR BAG DISABLED INDICATOR LAMP
ASR/ESP CLIMATRONIC BUTTON CONTROL MODULE (AUTOMATIC A/C)
BLK WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
CORNING
DATA BUS ON BOARD DIAGNOSTIC INTERFACE
DIAGNOSTIC CONNECTOR
ENGINE CONTROL MODULE
ENGINE CONTROL POWER MODULE STEERING CONTROL MODULE
FROM FUSE 30 (DIAGRAM 6 OF 6)
FROM FUSE 7 (DIAGRAM 2 OF 6)
FROM FUSE PANEL B (DIAGRAM 2 OF 6)
FUSE 1
FUSE 2
FUSE 3
FUSE 30 (2.0L)
FUSE 4
FUSE 5
FUSE 6
FUSE PANEL C (LEFT SIDE OF DASH)
GRN WIRE
HEADLAMP RANGE CONTROL MODULE (W/ HID)
HEATER/ HEAT OUTPUT SWITCH
INSTRUMENT CLUSTER CONTROL MODULE
LEFT HEADLAMP POWER OUTPUT STAGE
LIGHT SWITCH
LOAD REDUCTION RELAY
MULTIFUNCTION TRANSMISSION RANGE SWITCH
NCA WIRE
PARKING HIGH AID PRESSURE CONTROL SENSOR MODULE
POWER SUPPLY RELAY (TERMINAL 15)
POWER SUPPLY RELAY (TERMINAL 50)
POWER SUPPLY RELAY 2 (TERMINAL 15)
RED WIRE
RED/YEL WIRE
RIGHT HEADLAMP POWER OUTPUT STAGE
SEAT OCCUPIED RECOGNITION CONTROL MODULE (W/ REAR SIDE AIR BAG)
SELECTOR LEVER
STARTER
STARTER RELAY 1
TIRE PRESSURE MONITORING DISPLAY BUTTON
TO FUSE 2 (DIAGRAM 6 OF 6)
TO FUSE PANEL B (DIAGRAM 1 OF 6)
TO FUSE PANEL C (DIAGRAM 4 OF 6)
TO VOLTAGE STABILIZER (DIAGRAM 3 OF 6)
TRANSMISSION CONTROL MODULE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
YEL WIRE
Go to component -> Power distribution circuit, late production (6 of 6) -> LEFT HEADLAMP POWER OUTPUT STAGE
