Volkswagen Golf Mk6 (2008-2012) left front turn signal bulb Wiring diagram
This page shows the only wiring diagram for the component.left front turn signal bulb, which is found in the car Volkswagen Golf Mk6 (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front turn signal bulb (1 of 1)
2.5L 2.0L TURBO
ALARM HORN
AUTOMATIC A/C GLOW TIME COMPRESSOR CONTROL REGULATOR MODULE VALVE
AUXILIARY HEATER CONTROL MODULE
BLK WIRE
BRAKE FLUID LEVEL WARNING SWITCH
BRN WIRE
BRN/BLK WIRE
ENGINE HOOD CONTACT SWITCH
FUEL PUMP 2
GRN/YEL WIRE
HEADLAMP LEFT LOW RANGE/ BEAM CORNERING REFLECTOR LAMP CONTROL MOTOR MODULE
HEADLAMP RANGE/ CORNERING LAMP CONTROL MODULE
HEADLAMP WASHER PUMP
HEATER COOLANT SHUT-OFF VALVE
HIGH TONE HORN
LEFT ADAPTIVE CORNERING LAMP MOTOR
LEFT FRONT TURN SIGNAL BULB
LEFT HEADLAMP POWER OUTPUT STAGE
LEFT HEADLIGHT
LEFT HID HEADLAMP MULITI-FUNCTION CONTROL TRANSMISSION MODULE RANGE SWITCH
LEFT LOW BEAM HEADLAMP BULB
LEFT PARKING LAMP, LEFT DAYTIME RUNNING LAMP
LOW TONE HORN
NCA WIRE
RIGHT DAY- TIME RUNNING LAMPS, RIGHT HIGH BEAM HEADLAMP BULB
RIGHT DAYTIME RUNNING LAMP, PARKING LAMP CONTROL MODULE
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP POWER OUTPUT STAGE
RIGHT HEADLIGHT
RIGHT HID HEADLAMP CONTROL MODULE
RIGHT HIGH BEAM HEADLAMP BULB
RIGHT LOW BEAM HEADLAMP BULB
RIGHT LOW BEAM REFLECTOR MOTOR
RIGHT RIGHT SIDE FRONT MARKER TURN LAMP SIGNAL BULB BULB
RIGHT SIDE MARKER LAMP BULB
SENSOR FOR RIGHT VARIABLE HEADLAMP POSITIONING MOTOR
TRANSMISSION CONTROL MODULE
WIPER MOTOR CONTROL MODULE
Go to component -> Ground distribution circuit, late production (3 of 4) -> LEFT FRONT TURN SIGNAL BULB
